The Linkbasic CFJ01 is a durable 120mm panel cooling fan engineered to maintain optimal operating temperatures within server racks and network enclosures. Constructed with a heavy-duty aluminium frame and equipped with a protective nickel-plated finger guard, it provides efficient, quiet heat extraction to safeguard active equipment from thermal throttling.
Technical Specifications
- Model Code: CFJ01
- Brand: Linkbasic
- Operating Voltage: 250V AC, 50/60 Hz
- Dimensions: 120 mm × 120 mm × 38 mm
- Airflow Capacity: Up to 195 m3/h
- Noise Output: ≤ 48 dB
- Operating Temperature Range: 0 °C to 70 °C
- Frame Material: Aluminium
- Finger Guard Finish: Nickel-plated
- Colour: Black / Nickel-plated
- Mounting Orientation: Horizontal top/roof mounting or panel mounting
- Certifications: UL, CSA certified
Key Features
- Efficient Heat Extraction: Delivers up to 195 m3/h of airflow to continuously expel heat from densely populated server and patch cabinets.
- Robust Frame: Features a rigid aluminium housing designed for continuous operation and structural resilience in demanding networking environments.
- Integrated Safety Guard: Includes a nickel-plated steel finger guard to protect technicians and prevent loose cabling from contacting moving fan blades.
- Low Noise Operation: Engineered to operate at or below 48 dB to minimise ambient noise levels in office or equipment room setups.
- Standardised Compatibility: Built to standard 120 mm panel mounting dimensions for direct installation into Linkbasic free-standing and wall-mounted rack roofs or fan trays.
