The Ruijie Reyee RG-EG105GW(T) is a high-performance, all-in-one wireless business router designed for small-to-medium enterprises, retail spaces, hotels, and SOHO deployments. Featuring concurrent dual-band Wi-Fi 5 (802.11ac Wave 2) technology, gigabit ethernet ports, multi-WAN load balancing, and native Reyee Mesh support, it delivers robust routing, seamless wireless coverage, and effortless cloud management.
Technical Specifications
- Model Number: RG-EG105GW(T)
- Ethernet Ports: 5 x 10/100/1000 Base-T ports (1 fixed WAN, 1 fixed LAN, 3 switchable LAN/WAN ports)
- Wi-Fi Protocol: Wi-Fi 5 (IEEE 802.11ac Wave 2 / Wave 1, backward compatible with 802.11a/b/g/n)
- Wireless Rate: Dual-band concurrent up to 1267 Mbps (2.4 GHz: up to 400 Mbps; 5 GHz: up to 867 Mbps)
- MIMO & Streams: 2×2 MIMO across both 2.4 GHz and 5 GHz bands (4 spatial streams total)
- Antennas: Built-in omnidirectional antennas (2.4 GHz: 3 dBi, 5 GHz: 4 dBi)
- Hardware: Dual-core 880 MHz CPU, 256 MB DDR3 RAM, 32 MB SPI NOR Flash
- Recommended Clients: Up to 150 total clients (including up to 80-100 wireless clients)
- Power Supply: DC 12V/1.5A (Maximum power consumption: <= 15 W)
- Dimensions: 120 mm x 120 mm x 28 mm (excluding mounting bracket)
- Weight: 0.251 kg
Key Features
- Multi-WAN Load Balancing: Supports up to 4 WAN ports with intelligent load balancing and link failover to maximise internet uptime.
- Reyee Mesh Technology: Effortlessly pair and expand wireless coverage across multiple access points or routers at the press of a single button.
- Smart Flow Control & Behaviour Management: Optimise bandwidth usage with application identification, priority configurations, automated smart flow control, and website/app filtering policies.
- Built-in Gateway Controller: Can act as a master gateway to centrally manage up to 32 Ruijie/Reyee APs and 128 switches.
- Free Cloud Management: Remote configuration, real-time traffic monitoring, and captive portal setup (SMS, voucher, or one-click authentication) available via the Ruijie Cloud app.
