The Ruijie Reyee RG-RAP52-OD is a compact, high-performance AC1300 Wave 2 outdoor Wi-Fi 5 access point. Designed for versatility in villas, retail spaces, and street-facing business environments, it delivers reliable wireless coverage with a total throughput of 1,267 Mbps. Its weatherproof IP65-rated design and detachable antennas allow for flexible, customised installation in challenging outdoor conditions.
Technical Specifications
- Model Number: RG-RAP52-OD
- Wi-Fi Standard: Wi-Fi 5 (802.11ac Wave 2)
- Max Data Rate: 1,267 Mbps (400 Mbps at 2.4 GHz; 867 Mbps at 5 GHz)
- MIMO: 2×2 MIMO (2.4 GHz and 5 GHz)
- Ethernet Port: 1 x 10/100/1000 Base-T Gigabit port
- Power Supply: IEEE 802.3af PoE or 24V Passive PoE
- Weatherproof Rating: IP65
- Surge Protection: 4kV Lightning protection, 15kV ESD shielding
- Client Capacity: Up to 110 concurrent users
- Operating Temperature: -30°C to +65°C (-22°F to +149°F)
- Dimensions: 220 mm × 50 mm × 35.7 mm (excluding mounting bracket and antenna)
Key Features
- Reyee Mesh & AI Roaming: Supports intelligent mesh networking and seamless roaming, ensuring uninterrupted connectivity across multiple access points.
- Flexible Installation: Compact form factor with support for both wall and pole mounting.
- Detachable Antennas: Includes two external omnidirectional antennas that can be adjusted or replaced to optimise coverage for specific outdoor layouts.
- Cloud Management: Easily monitor and configure your network locally via the eWeb interface or remotely using the Ruijie Cloud app/platform without needing an extra controller.
- Durable Design: Specifically engineered to resist dust, rain, and extreme temperatures, making it a reliable choice for long-term outdoor deployment.
