The Ubiquiti airMAX NanoStation 5AC Loco (LOCO-5ACL) is a compact, high-performance 5GHz radio designed for cost-effective wireless connectivity. Featuring a 13dBi integrated antenna and an updated airMAX AC chipset, it is ideal for Point-to-Point (PtP) links or as a Client Premises Equipment (CPE) in Point-to-Multipoint (PtMP) deployments. With its dedicated 2.4GHz management radio, setup and configuration via the UISP platform are streamlined and efficient.
Note: This unit does not ship with a PoE injector. To ensure proper operation, we recommend powering this device using a 24V, 0.3A Gigabit PoE adapter (such as the Ubiquiti UPOE24-12W). The unit requires 24V Passive PoE; it is not compatible with standard 802.3af/at PoE switches without an additional converter.
Technical Specifications
- Model Number: Loco5AC
- Networking Interface: 1 x Gigabit RJ45 Port
- Operating Frequency: 5 GHz (with dedicated 2.4 GHz Management Radio)
- Antenna Gain: 13 dBi
- Power Method: 24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
- Max. Power Consumption: 7W
- Operating Temperature: -40 to 70° C (-40 to 158° F)
- Enclosure Material: UV-stabilised Polycarbonate
- Mounting: Pole Mount (Included)
Key Features
- Versatile Deployment: Optimised for both short-range PtP bridging and PtMP CPE installations.
- airMAX AC Technology: Delivers high throughput and improved performance over traditional airMAX protocols.
- Easy Management: Includes a dedicated 2.4GHz Wi-Fi radio for fast, convenient setup via the UISP mobile app.
- Durable Design: Built for outdoor environments with a weather-resistant, UV-stabilised enclosure.
